Fermod 471HP Rising Cold Room Door Hinge
Fermod 471HP Cold Room Door Hinge - Rising
- Rising hinges to suit rebated doors
- Interchangeable for left and right-hand doors.
- For doors of 48 to 80 mm thickness (including gasket)
- 180° opening
- Used Foster Coldstore doors
Things to note:
- Several hinges in this range look similar.
- The code on the inside of the hinge cover is 0470 on all models of this hinge.
- The 473HP has a black composite adjusting mechanism behind the bottom cover.
- 470HP - Non-Rising
- 471HP - Rising - (Found on Foster Coldstore Doors)
- 472HP - Non-Rising Adjustable
- 473HP - Rising Adjustable
Max door weight 40kg
